Zgonic Monitor Arm




With its innovative design and cutting edge technology, Zgonic sets a precedent in bringing an ergonomic experience to discerning users. It has highly flexible adjustments to fit you comfortably. Simple installation and high adaptability with different monitors are further testaments to its design with you in mind.

Maximise your viewing comfort and improve productivity. With its multi-adjustment capabilities including height adjustability, tilt, swivel and pivot, Zgonic lets you move the monitor to your desired position and collaborate with ease.

Body Colour: Silver or Black with 5 side arm panel colour options

Features

Latest Spring Technology
Zgonic's spring is compressed to provide a balancing force against the monitor weight (ranging from 2.5 kg to 9 kg). Zgonic monitor arm allows the monitor to "float" and to be adjusted effortlessly and continuosly.

Concealed Cables
Monitor cables are cleverly contained, retained and hidden from view.

Unparalled Usability
Zgonic monitor arm is unique "four bar" mechanism provides smooth and frictionless tilt to create glare free viewing on the screen.

Tool-less Adjustment
Tool-less adjustment of the spring compression is achieved by winding the retractable knob which is linked to the spring via an ingenious gear box and bevel gear system.

Spring Tension Indicator Gauge
Zgonic monitor arm has a spring compression gauge which allows pre-setting of the calibration, faster installation and lower labout cost.

Quick Release Mounts
Zgonic monitor arm offers two quick release mechanisms enabling rapid screen interchange or alternatively replacement of the screen with a laptop.

180° Lock-Out
This unique feature prevents the monitor from colliding with a glass wall or privacy screen.

Tool-less Installation
Zgonic monitor arm has two piece interlocking desk clamp provides rapid, efforless attachment to desktops with a thickness range of 18 mm to 60 mm

Warranty
3 Year limited hardware warranty


Specifications
Weight Capacity 2.7 kg to 9 kg
LCD Size 19" to 27"
Tilt -4° to +20°
Rotation 360° for portrait or landscape viewing
Arm Reach 634 mm
Height Adjustment Range 296 mm
Mounting Desk Clamp attaches to surface edge 18 to 60 mm thick.
Display Compatibility VESA 75/100mm
